Helical Focusers: Diving Deep into My Expertise
Astronomical helical focusers are essentially oversized screws with an opening for an eyepiece. The twisting screw threads within the draw tube interact with equivalent threads in a receptacle. These focusers are relatively easy to construct to precise standards, making them a common addition in star diagonals, binoviewers, and even eyepiece holders in telescopes like the Questar.
However, their efficiency is somewhat compromised due to the time it takes to make coarse adjustments with finer threads and the potential for deflection and wobble with heavier accessories. To name a few benefits, they are affordable, robust, lightweight, offer a good degree of fine adjustment, and are relatively low-profile. But they come with drawbacks such as time-consuming coarse adjustments, deflection/wobble with heavier accessories, rotating the entire eyepiece/diagonal/camera (except in nonrotating designs), and the challenge to motorize them.
Nonrotating helical focusers, particularly in smaller refractors and guide scopes designed for astrophotography, prevent the twisting of the drawtube by keeping it on a slotted track. This eliminates the rotation that is annoying when attempting astrophotography.
Helical Crayford focusers replace the threaded drawtube with a smooth one and introduce angled rollers in place of the threaded receptacle. These focusers provide smooth, precise focusing, do not rotate the camera or eyepiece, and can support heavier cameras and eyepieces without slippage. The downside is that they are more complex, potentially bulkier, and prone to mechanical wear due to the inclusion of more moving parts.
Notably, the hybrid helical Crayford design offers a resolution to the issues that plague both pure helical and standard Crayford focusers. This combination enables linear focusing without image rotation while providing greater nuanced focus adjustments compared to standard Crayford models for high-precision astrophotography. Some examples of quality helical Crayfords include the KineOptics HC-2 and HC-1, and DIY versions can be easily constructed using readily available hardware.
In summary, while simple helical focusers can suffice for visual use or lightweight imaging, they are less ideal for serious astrophotography. The helical Crayford, with its precise, stable focus and ability to handle heavy imaging equipment, is generally more suitable for astrophotography pursuits.
